Reliable Structural
and
Low Failure Rate
High Controllability
and
Wider High Efficiency Range
High Power Density
and
High Over-Load Capacity
Excellent Security
and
Insulation Level H, Protection Grade IP67
MOTOR FEATURES
PRODUCT PARAMETERS
Controller parameters
Model No.
RTD010A
Rated input voltage (Battery voltage) (Vdc)
350Vdc （250Vdc-450Vdc）
Constant output current (Arms)
250
Max output current (Arms)
450
Rated capacity (KVA)
100
Max capacity (KVA)
200
Protection level
IP67/IP6K9K
Auxiliary power supply voltage (V)
12V/24V
Dimension (L*W*H in mm)
261*210*112
Weight (kg)
6.8
Motor parameters
Model No.
RTM210.140
Rated power (Kw)
45
Max power (Kw)
90
Rated torque (N.m)
128
Max torque (N.m)
285
Rated speed (rpm)
3357
Max speed (rpm)
10000
Insulation
H
Cooling
Liquid cooling
Protection level
IP67
Rotation direction
Clockwise/Anti-clockwise
Dimension (External diameter / length)
260*264.5
Shaft type
out spline
Weight (kg)
49.5
CONTROLLER-FEATURES
Modular design compact structure
Space vector control high interference resistance
Control maximum torque with minimum current
Stable and reliable Operation
Design and manufacture in accordance with automotive standards
OUTLINE DRAWING
TECHNICAL DOCUMENT
Datasheet
Download
Power/Torque curve & efficiency map
Download
Drawings
Download
